| Max. working height |
mm |
8000 |
10000 |
12000 |
| Max. Platform height |
mm |
6000 |
8000 |
10000 |
| Rated capacity |
kg |
300 |
300 |
300 |
| Folding Max. height (guardrail unfolding) |
mm |
2150 |
2275 |
2400 |
| Folding Max. height (guardrail removed) |
mm |
1190 |
1315 |
1440 |
| Overall length |
mm |
2400 |
2400 |
2400 |
| Overall width |
mm |
1150 |
1150 |
1150 |
| Platform size |
mm |
2270x1150 |
2270x1150 |
2270x1150 |
| Platform extend size |
mm |
900 |
900 |
900 |
| Min. ground clearance (lowered) |
mm |
110 |
110 |
110 |
| Min. Ground clearance (lifted) |
mm |
20 |
20 |
20 |
| Wheelbase |
mm |
1850 |
1850 |
1850 |
| Min. Turning radius (inner wheel) |
mm |
0 |
0 |
0 |
| Min. Turning radius (outer wheel) |
mm |
2100 |
2100 |
2100 |
| Power souce |
V/kw |
24/3 |
24/3 |
24/3 |
| Runing speed (rising) |
km/h |
4 |
4 |
4 |
| Rising/falling speed |
sec |
40/50 |
40/50 |
70/80 |
| Battery |
V/Ah |
4x6/210 |
4x6/210 |
4x6/210 |
| Charger |
V/A |
24/25 |
24/25 |
24/25 |
| Max. Climbing ability |
% |
20 |
20 |
20 |
| Max. working allowable angle |
° |
2-3 |
2-3 |
2-3 |
| Control type |
|
Electro-hydraulic proportion control |
| Drive |
|
Double front-wheel |
| Hydraulic drive |
|
Double rear wheel |
| Wheelsize (non-marking solid tire) |
|
381x127 |
381x127 |
381x127 |
| Service weight |
kg |
1900 |
2200 |
2700 |
