Feature： |
|
|
1.Configuration of the pumping station and wheel imports and imports of electronic control systems, performance
2.Configuration of the traction battery capacity, charge fast and convenient, durable consumption, with power indicator, low-voltage warning light
3.Gantry tilt a certain angle and a high degree of freedom to enhance
4.Apply to operate single-sided double-sided pallet cargo tray
5.With low-voltage protection, the battery voltage when the voltage is lower than the protection of the use of batteries, to extend the service life of
6.In line with the European EN1757-1: 2001, EN1727 standard |
|
|
Specifications： |
|
|
| Model |
|
CQD10B-30 |
CQD12.5B-30 |
CQD15B-30 |
| Load Capacity Q |
kg |
1000 |
1250 |
1500 |
| Load Center |
mm |
400(500) |
400(500) |
400(500) |
| Max. Lifting Height H |
mm |
3000 |
3000 |
3000 |
| Free Lift |
mm |
(150+1500) |
| Degree of Tilt Angle |
|
2 ゜ / 5 ゜ |
2 ゜ / 5 ゜ |
2 ゜ / 5 ゜ |
| Fork Length L3 |
mm |
1000 |
1000 |
1000 |
| Lifting Speed (Laden/Unladen) |
m/min |
5 |
5 |
5 |
| Travel Speed (Laden/Unladen) |
km/hr |
5/4.5 |
5/4.2 |
6.5/5.5 |
| Gradeability (laden/unloaden) |
% |
8/5 |
8/5 |
8/5 |
| Turning Radius R1 R2 |
mm |
H1:1600, H2:2050 |
H1:1660, H2:2020 |
H1:1725, H2:2180 |
| Reach Stroke L2 |
mm |
600 |
600 |
600 |
| Frame Length L1 |
mm |
1660 |
1718 |
1785 |
| Frame Width W2 |
mm |
868 |
868 |
1040 |
| Mast Height |
Mast Lowered |
mm |
2150 |
| Mast Lifted |
mm |
3510 |
| Straddle Leg Height K |
mm |
258 |
258 |
258 |
| Wheel Base |
mm |
1350 |
1420 |
1490 |
| Wheel Tread (Front) |
mm |
1030 |
| Fork Adjusting Distance W |
mm |
220~700 |
| Weight (Incl. battery) |
kg |
1500 |
1650 |
1850 |
| Wheel |
Front Wheel |
mm |
Polyurethane 210X85 x 2EA |
| Rear Wheel |
mm |
Polyurethane 250X90 x 1EA |
| Balance Wheel |
mm |
Polyurethane 160X60 x 2EA |
| Control System |
Drive Control |
MOSFET |
MOSFET |
MOSFET |
| Hydraulic Control |
MOSFET |
MOSFET |
MOSFET |
| Motor |
Drive Motor |
1.5kw |
1.5kw |
1.5kw |
| Hydraulic Motor |
2.8kw |
2.8kw |
3.0kw |
| Battery |
Voltage |
24V |
24V |
24V |
| Capacity |
240AH |
240AH |
240AH |
| Charger |
System |
Intelligent |
Intelligent |
Intelligent |
| Input Power Source |
50Hz, 220V/380V |
50Hz, 220V/380V |
50Hz, 220V/380V |
Remark:
1.Spercial lifting height is available.
2. Germany origin imported REMA, FREI tiller is option.
3. Can be with armrest and forged forks.
4. The specification in the table are ofr standard models only, for further information, please contact with us. |
|
|
|
|
|
